110V LT-150D
automatic desktop conveyor table round bottle
high speed marking
and labeling machine |
|
|
|
|
|
|
|
The
machine is beautiful, smart, and has a high qualification rate. It is
suitable for labeling and coding in cosmetics, beverages, medicine,
food, general merchandise and other industries.
The design of the machine is novel and unique, and the operation and
adjustment are very convenient. The operator only needs to place the
bottle on the conveyor belt，when the bottle moves forward, the cursor
will automatically label and mark the bottle after detecting it.
It can be used for both stand-alone production and online production. |
|
 |
|
Product parameter: |
 |
|
Voltage: |
110V/60Hz |
|
Material: |
The
surface is stainless steel |
|
Conveyor width:
|
5.9in(15cm) |
| Conveyor belt length: |
45.86IN(116.5CM) |
| Label inner diameter： |
2.99in(7.6cm) |
| Label outer diameter: |
9.8in(25cm) |
| Label out: |
Left bid |
|
Output speed: |
20-200PCS/min (Depending on
the bottle size and label length) |
| Suitable bottle diameter: |
1.57-3.9in(4-10cm) |
|
Label height： |
0.59-5.9in(1.5-15cm) |
| Label length： |
0.98-11.8in(2.5-30cm) |
| Precision: |
±0.039in（1mm) |
|
Package: |
Export wooden case |
|
|
Feature: |
|
|
|
 |
 |
 |
|
 |
|
|
|
|
|
|
|
Product analysis: |
 |
 |
|
1. Intelligent
control panel
2. power switch
3. Start key
4. Emergency
stop switch
5. Spoke speed
control knob
6. Transmission
speed control knob
7. Label sensor
8. Conveyor belt
motor
9. Conveyor belt
10. Wheel
auxiliary pressure plate
11. Wheel
auxiliary belt
12. Coding
machine
13. Labeled
assembly lifting hand wheel
14. Wheel
auxiliary pressure plate lifting hand wheel
15. Receiving
drum
16. Guardrail
17. Guardrail
adjusting knob
18. Front and
rear adjusting hand wheel of wheel auxiliary pressing plate
|
|
Product
safety precautions: |
To ensure safe production, please read the
following precautions carefully:
1. Use the power supply that meets the requirements of the machine.
2. After turning off the power switch, there is still voltage in some
circuits in the electrical control of the machine. When servicing the
control circuit, be sure to unplug the power cord.
3. Do not touch the print grain holder with your hands during work to
prevent scalding and pay attention to personal safety.
4. When the machine has problems, press the emergency stop button
directly to suspend all work. |
|
Details: |
|
 |
 |
 |
 |
 |
|
Package
Include
(160173): |
 |
 |
|
Advantages:
|
|
1. The machine is efficient and convenient to use;
2. The machine automatically labels, saving manpower and material
resources;
3. This machine has wide applicability and stable performance;
4. This machine is equipped with intelligent touch control screen, which
is more convenient to set data parameters;
5. This machine can meet the requirements of full-circle labeling or
semi-circle labeling of round bottles. The labeling switching between
bottles is simple, and the labeling is flat without wrinkles to improve
the packaging quality.
6.This machine can be used with capping machine and bottle sorting
machine.
7.The components of each adjustment position are precisely matched, and
the height, width and width of the components can be easily adjusted
without the use of professional tools. The machine operation is simple
and simple.
|
|
Product display: |
 |
|
 |
|
|
 |
|
Item include：LT-150D
automatic desktop conveyor table round bottle high speed marking and
labeling machine*1 |
|
Item Number: 160173 |
|
|
You can make order
with no worry.
Any concerns just feel free to let us know, we'll reply in 24 hours in
normal condition.
Handling Time: Shipping is usually made in 1-3 business days after
payments cleared. Orders are processed from Monday-Friday; Not on the
weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the consumables.
