1. Double-pulse micro-computer spot welding and
battery charger;
2. Micro-computer control up to level 199 (99*1,
99*2), precision parameter setting;
3. One or two pulse welding mood selectable;
4. Has the fast setting knob of pulse serial (16
pulse), suitable for the welding of thicker material;
5. Has adjustable charger (4.2 - 36 V, 0 - 3 A),
convenient for the charging and test of battery;
6. The specific battery tester can test the
float charge voltage, therefore, you can get the internal resistance by
selecting the appropriate charging current.
7. It have foot switch and pressure adjuster,
which ?improves the accuracy of welding.
1. Spot welding machine
Input Voltage: AC 110 V
Primary Current: 2 - 15 A
Welding Current: 50 - ?800 A (The corresponding
pulse time: 1 ms - 19 ms)
2. Numerical control charger:
Charging Voltage: 4.2 - 36 V (Adjustable)
Charging Current: 0 - 3 A (Adjustable)
3. Weight: 4.3 kg
4. Dimensions: 140 x 245 x 200 mm
5. Range of sheet metal Welding Thickness: 0.1 -
0.2 mm; For pure
nickel strip: 0.1 - 0.15 mm
6. Electric leakage Switch Requirement: 60 A or
more than 60 A
